Product Specification

The industrial Android panel pc adopts industrial-grade aluminum structure and high-efficiency heat dissipation structure, which can adapt to various complex and harsh application scenarios with high dust and stable operation in high and low temperature environments.

011

021

Rich ports can meet your all demand, also support customized ports.

Our Android panel PC is engineered to perform seamlessly in extreme temperatures. With an operating range from -20°C to 70°C, it's perfect for various harsh environments. Whether it's the frigid cold of a warehouse or the sweltering heat of an industrial site, this panel PC won't let you down. Reliable and durable, it ensures continuous operation and optimal performance, meeting all your demanding needs.

Pure screen capacitive touch, high resolution, sensitive response, no lag, no blind spots, and high stability, support 10-point touch.

The machine has passed IP65 certification, which can effectively waterproof splash and dust, and can be used in difficult working environments.

The all-aluminum body has a good heat dissipation effect, a fanless silent design, ande zero noise. Even under high- intensity work, it can stabilize performance in real time and extend the service life of the machine.

This model has 7, 10.1 inch can be chosen, we also have other smaller or bigger size model, please feel free to contact with us:)

Different installation ways for you.

product-750-659

Application:

Industrial android panel pc is an essential tool for a variety of industrial applications. The product is widely used in agricultural environments, construction sites, the oil and gas industry, and the mining industry.

LCD screen	Type	10.1 inch Full Fit Industrial LCD (LED Backlit)	7 inch full-fit industrial LCD (LED backlight)
Resolution		1280 * 800	1024 * 600
Visual angle		85/85/85/85 (Typ.)(CR≥10)
Brightness		350nits	300nits
Contrast		800:01:00	500:01:00
Backlight life		30,000 hr (min.)
Touch screen	Type	Projective capacitive touch, 10-point touch
Control mode		USB interface
Light transmittance		Over 80%
Operating temperature		-10℃～60℃
Storage temperature		-20℃～70℃
Relative humidity		5% -95% relative mixing, non-condensing
Body weight	Net bare weight	TBD
Installation		Support for VESA installation/embedded panel installation

Processor		Rockchip RK3568 UP to 2GHz	Rockchip RK3562 UP to 2GHz	Rockchip RK3576 UP to 2.2GHz
System	GPU	ARMG52 2EE GPU Graphics Processing		ARM G52 MC3 GPU Graphics Processing
	Memory	Standard 2G LPDDR4 (optional 4G/8G)		Standard 2G (optional 4G/8G) LPDD4X/LPDDR4
	System built-in memory	Standard 16G EMMC (optional 32G/64G/128G/256g)
	NPU	1T OPS NPU	1T OPS NPU	6T OPS NPU
	Networ(LAN)	1 * RTL8201F 100M network port/optional 2 * RTL8201F 100M network port 1 power switch (steady on)	1 * RTL8201F 100M network port	2 * RTL8211F-CG gigabit network port
I/O interface		1*power switch (always on)
		1 * DC IN 12V (optional 9-36V wide voltage)	1*DC IN 12V	1 * DC IN 12V (optional 9-36V wide voltage)
		1*HDMI	1 * Horn output (2 * 18W 4R)	1*HDMI
		1 * Audio 2-in-1 (microphone in/line out)
		1*LAN	1*LAN	2*LAN
		1 * Upgrade button
		2USB3.0(1USB3.0 HOST/1*USB3.0 OTG)
		2*USB2.0(optional LAN)	2*USB2.0	/
		4COM(2RS233,2*RS232/RS485)
		1*GPIO(4-way)
		1*SIM card slot
Expand		1 * mini-PCIe slot supporting 4G/5G module (optional)
		supporting software watchdog
Operating system		Android 11/Ubuntu20.04/Debian11	Android 13/Ubuntu20.04/Debian11	Android 14/Ubuntu20.04/Debian11
